2025 Kawasaki KLX230 S

Standard

• Starting - Electric
• Final Drive - Chain
• Bore x Stroke - 67.0 x 66.0 mm
• Compression Ratio - 9.4:1
• Fuel System - Fuel injection: ø32 mm x 1
• Transmission - 6-speed, return
• Lubrication - Forced lubrication, wet sump
• Clutch: Wet multi-disc, manual
• Engine - 233cc, air-cooled, 4-stroke, SOHC 2-valve single
• Ignition -Digital

Standard

• Kawasaki Protection Plus - 12 / 24 / 36 / 48 months
• Warranty - 12 months
• Road Clearance - 240 mm (9.4 in)
• Curb Mass - 132 kg (291 lb)
• Fuel Capacity - 7.6 litres
• Instrumentation - LCD screen with speedometer, odometer, dual trip meters, fuel gauge, clock, smartphone call and mail notices, Bluetooth indicator, and a range of indicator lamps
• Dimensions (L x W x H) - 2,080 x 845 x 1,140 mm (81.9 x 33.3 x 44.9 in)
• Wheelbase - 1,365 mm (53.7 in)
• Seat Height - 845 mm (33.3 in)
• Estimated Dry Weight - 125 kg (275 lb)

Standard

• Smartphone Connectivity
• ERGO-FIT
• Selectable ABS
• ABS ( ANTI-LOCK BRAKE SYSTEM)

Standard

• Steering Angle (L/R) - 45° / 45°
• Frame - Perimeter, high-tensile steel
• Front Tire - 2.75-21 45P
• Rear Tire - 4.10-18 59P
• Front Suspension / Wheel Travel - ø37 mm telescopic fork / 200 mm (7.9 in)
• Rear Suspension / Wheel Travel - New Uni Trak with adjustable spring preload / 223 mm (8.8 in)
• Rake / Trail - 24.6° / 96 mm
• Front Brake: ø265 mm petal disc with dual-piston caliper
• Rear Brake: ø220 mm petal disc with single-piston caliper
