2025 Yamaha VIKING

Standard

• Lubrication - Wet sump
• Final Drive - Shaft
• Ignition - TCI
• Starting - Electric
• Fuel Delivery - Mikuni 44mm throttle body F.I.
• Engine - 686cc, liquid-cooled, SOHC, 4-valve, single
• Bore and Stroke - 102mm x 84 mm
• Compression Ratio - 10.0: 1
• Transmission - Yamaha Ultramatic CVT with reverse & On-Command (2WD, 4WD limited slip, 4WD diff-lock)

Standard

• Brakes (Front) - Dual 207 mm discs / twin piston calipers
• Brakes (Rear) - Dual 207 mm discs / twin piston calipers / Shaft mounted parking brake
• Tires (Front) - AT25 x 8-12
• Tires (Rear) - AT25 x 10-12
• Suspension (Front) - Independent double wishbone / 205 mm (8.1") of wheel travel
• Suspension (Rear) - Independent double wishbone with anti-sway bar / 205mm (8.1") of wheel travel

Standard

• Length - 3,100 mm (122")
• Width - 1,570 mm (61.8")
• Fuel Capacity - 36.7 litres (8.1 Imp. Gal)
• Bed Capacity - 272 kg (600 lb)
• Towing Capacity - 680 kg (1,500 lb)
• Height - 1,925 mm (75.8")
• Wheelbase - 2,135 mm (84.1")
• Ground Clearance - 300 mm (11.8")
• Warranty - Private use - 1 year (unlimited mileage), Commercial use - 6 months (unlimited mileage)
• Turn Radius - 4,500 mm (177")
• Weight - 644 kg (1,420 lb)
